Industrial Dough Kneading Machine

  • Material:Flour,water
  • Capacity:50 kg/h
  • Loading Port:Qingdao Port Port
  • Description:Here introduce operation method and the matters needing attention for industrial dough kneading machine.
Features
Dough Kneading MachineOperation method and the matters needing attention for industrial dough kneading machine
1, The method of operation:
Connect power supply, switching, make the machine run properly; Put flour, water and other material into the noodles hopper, start stirring, when reach the required mixing procedures, stop, pull out the bolt to make hopper incline up 90 degree, and then pour out the mixed dough.
2, Note:
(1) Deviation of power supply voltage use of this machine is not more than plus or minus 5%.
(2) Must operate according to the rated amount, and decrease flour if the mixed dough is hard. Don't allow dough fermentation inside the machine box. Rated dough mixing volume ratio of water and flour as 0.45-0.5:1.
(3) When mixing flour, put the flour first and then add water, no reverse. Only and after the completion of the dough mixing can be inversed to pour out the dough.
(4) When booting, hands and other items are forbidden to put into inside the machine box, lest risk.
(5) After using the dough kneading machine, cut off the power supply, clean up, coating with a layer of oil on the electroplating parts in case rust

Technical Data
Model Capacity
(kg/time)
Voltage
(V)
Power
(kw)
Size
(mm)
GG-15 15 220/380 1.1 640*420*630
GG-25 25 220/380 2.2 900*650*900
GG-50 50 380 3 1170*850*950
GG-75 75 380 4 1170*720*1400
